306-25 Metering Pump
For metering larger quantities of 105 Resin and 205 Fast or 206 Slow Hardeners. The 306-25 Metering Pump will reduce mixing time and waste on large projects. A carrying handle allows you to move the pump where the work is. Reservoirs hold one gallon of resin and one quart of hardener. Dispenses approximately 0.5 fl oz of resin/hardener per pump stroke (about one qt per minute).
Designed for Use with:
Product Specifications:
Dispenses five parts resin and one part hardener (5:1) by volume.
- Two separate parallel pump systems, one for the resin and one for the hardener
- Single lever pump-system
- The pump delivers 0.5 fl oz of resin and hardener per full stroke
- Calibrated for WEST SYSTEM 5:1 ratio epoxies (205 Fast Hardener or 206 Slow Hardener)
- Can be converted to a 3:1 ratio
Product Uses:
Streamlines the metering process for high-volume users
- 105 Resin and 205 or 206 Hardeners
- Quickly dispenses proper mix for large batch processes
- Reduces mixing time on large projects
- Convenient carrying handle to bring the pump where the work is
Ratio Ranges:
Check the ratio of resin to hardener dispensed by the pump before using. Recheck the ratio periodically or if you later experience incomplete or unusually fast or slow curing.
- Weight Ratio Range
- 105/205 [4.8:1 | 6:1]
- 105/206 [4.8:1 | 6.2:1]
- Volume Ratio Range
- 105/205 [4.4:1 | 5.5:1]
- 105/206 [4.3:1 | 5.5:1]
Pumps & Large Batch Mixing Methods
QUICK LINKS Helpful Tips, Safety Guidelines, Manuals, and More:
Thickening
Modifying with fillers and additives makes WEST SYSTEM epoxy extremely versatile for a wide variety of bonding and coating applications. Epoxy can be thickened to the ideal consistency needed for a particular job. Epoxy thickened with adhesive (high-density) fillers strengthens structural bonds, bridges gaps, and fills voids. Epoxy thickened with fairing (low-density) fillers is easily sanded and shaped after it cures.
