Rebuild Kit For All 306 Pumps
An epoxy pump rebuild kit for all 306 resin and hardener dispensing pumps. Compatible with the 306-23 Metering Pump (3:1 ratio for 207 or 209 Hardener) and the 306-25 Metering Pump (5:1 ratio for 205 or 206 Hardener). Our 306 Model A Dispensing Pumps consist of two separate, parallel systems, one for the resin and one for the hardener. Each has a spring-loaded poppet-type intake valve, a piston with an O-ring seal, and a spring-loaded ball check exhaust valve.
Designed for Use with:
Product Includes:
- seals
- balls
- gaskets
- springs
- high-rise tubes with ferrules
- new resin and hardener reservoirs with lids
Product Uses:
Compatible with 306 Model-A pumps sold before June 2005 (identified by a single resin/hardener pump body)
- 306-23 Metering Pump
- 306-25 Metering Pump
Epoxy Ratio Ranges:
Check the ratio of resin to hardener dispensed by the rebuilt pump before using. Recheck the ratio periodically or if you later experience incomplete or unusually fast or slow curing
- Weight Ratio Range
- 105/207 [3.4:1 | 4.2:1]
- 105/205 [4.8:1 | 6.2:1]
- 105/206 [4.8:1 | 6.2:1]
- 105/209 [3.3:1 | 4:1]
- Volume Ratio Range
- 105/207 [2.9:1 | 3.5:1]
- 105/205 [4.4:1 | 5.5:1]
- 105/206 [4.2:1 | 5.4:1]
- 105/209 [2.8:1 | 3.4:1]
Pumps & Large Batch Mixing Methods
QUICK LINKS Helpful Tips, Safety Guidelines, Manuals, and More:
Thickening
Modifying with fillers and additives makes WEST SYSTEM epoxy extremely versatile for a wide variety of bonding and coating applications. Epoxy can be thickened to the ideal consistency needed for a particular job. Epoxy thickened with adhesive (high-density) fillers strengthens structural bonds, bridges gaps, and fills voids. Epoxy thickened with fairing (low-density) fillers is easily sanded and shaped after it cures.
